About This Item

Item Description:

Parker 7000 Series Solenoid Valve 2-Way Normally Closed 3/8"" NPT 5-300 PSI

Parker 73212BN3SN00N0C111C2 Solenoid Valve 2-Way Normally Closed, 3/8" NPT



Product Series: 7000 Series

Body Material: Brass

Valve Type: 2-Way

Flow Factor 1 (Cv): 2.4

Function: Normally Closed

Port Size: 3/8 inch

Coil Type: 1/2" NPT Conduit, 18" Leads, Class F, NEMA 4X

Input Voltage: 24 VDC

Body Material: Brass

Seal Material: NBR

Orifice 1 Size: 7/16 inch

Flow Coefficient 1: 2.4 Cv

Power Consumption: 10 Watt (DC) W

Coil Type: 1/2" NPT Conduit, 18" Leads, Class F, NEMA 4X

Maximum Pressure Differential: 300 psi (DC) psi

Number of Ports: 2

Actuation Type: Manual/Mech. Operated

Media: General Purpose for Air, Liquids and Gases

Port Type: NPT

Orifice 2 Size: n/a

Flow Coefficient 2: n/a

Minimum Pressure Differential: 5 psi

Minimum Fluid Temperature: 0 °F

Maximum Fluid Temperature: 185 °F

Coil Specifications Met: NEMA 4X

Voltage (V): 24 VDC

Power (Watts): 10 Watt (DC)

Orifice 1 Size (inch): 7/16

Maximum Pressure Differential (psi): 300 psi (DC)

Seal Material: NBR
This Item May Interchange With The Following:
2052334
