Item Description:
Toro 260 Series Electrical Demystification Guide Wiring Diagrams Manual
This listing features an original Toro 260 Series Electrical Demystification Guide, Form No. 492-4404. This comprehensive service manual provides detailed wiring diagrams and troubleshooting procedures for the electrical systems of Toro 260 Series riding mowers, covering both single and twin cylinder hydrostatic models. Key sections include diagrams for ignition, PTO, seat, spark, charging, electric clutch, lights, hourmeter, park brake, battery, and oil pressure circuits, along with component descriptions for relays, fuses, and indicator lights. The manual shows signs of use, including visible dirt, stains, and creasing on the covers, with punched holes for binder insertion. All visible pages appear present and legible, making it an invaluable resource for electrical diagnostics and repair.
This is a Genuine OEM Manual (unless otherwise noted) not a grainy reprint made in some guy’s garage. I recently purchased a huge lot of manuals from a 75+ year Massey Ferguson dealership that closed. This manual has been used in a repair shop and may have dirt, grease, fingerprints, writing, and smudging on some pages.
